1. Gaskets
  2. Suzuki
  3. OEM 11173-49224-Mtl A

Valve Cover - Mtl A OEM 11173-49224-Mtl A

Valve Cover - Mtl A gasket, OEM 11173-49224-Mtl A. A, 20mm thick. Fits 4 listed machines.

Suzuki Valve Cover - Mtl A gasket outline, OEM 11173-49224-Mtl A, A material

Outline shown for identification — not to scale. The cut file is available to subscribers.

Specifications

OEM Number 11173-49224-Mtl A
Gasket Type Valve Cover - Mtl A
Material A
Thickness 20 mm
Gaskets in Set 1
Gasket Code 11173-22

Fits 4 machines

Make Model Years
Suzuki GS1100 1981 - 1982
Suzuki GS750L 1981
Suzuki GS750T 1982
Suzuki GSX750 1982 - 1983

Cut File

The cut file for this gasket is available to subscribers. Specifications above are free to view.

Subscribe to Download
